| PartNumber | LS029B3SX05 |
| Brand | Sharp |
| Size | 2.9 |
| Application | HMD VR AR |
| Resolution | 1440(RGB)×1440, 705PPI |
| Composition | CG-Silicon , LCM |
| Brightness | 150 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 16.7M |
| Backlight | 2 |
| Interface | |
| Panel Brand | Sharp |
| Panel Size | 2.9" |
| Display Area | 51.84(W)×51.84(H) mm |
| Outline Size | 54.24(W)×59.02(H) ×1.51(D) mm |
| Viewing Angle | - |
| Best View on | Symmetry |
| Display Colors | 16.7M 70% NTSC |
| Frequency | 120Hz |
| Weight | 7.00g (Typ.) |
| Panel Model | LS029B3SX05 |
| Panel Type | CG-Silicon , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | - |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Display Mode | SFR, Normally Black, Transmissive |
| Response Time | 10 (Typ.)(Tr+Td) |
| Lamp Type | 2 strings WLED , Without Driver |
| Touch Screen | Without |
