| PartNumber | LS055R3SX01 |
| Brand | Sharp |
| Size | 5.5 |
| Application | Mobile Phone |
| Resolution | 1536×2560 |
| Composition | CG-Silicon , LCM |
| Brightness | |
| CR | 1280:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Diagonal Size | 5.5 inch |
| Pixel Format | 1536(RGB)×2560 546PPI |
| Active Area | 71.424(H)×119.04(V) mm |
| Luminance | 460 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Support Color | 16.7M 70% NTSC |
| Weight | 21.1g |
| Frame Rate | 60Hz |
| Interface Type | MIPI (4 data lanes) , 32 pins Connector |
| Power Supply | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| Environment | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| Model | LS055R3SX01 |
| Type | CG-Silicon , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 73.824(H)×126.44(V) ×1.4(D) mm |
| Contrast Ratio | 1280:1 (Typ.) (TM) |
| Response Time | 30 (Typ.)(Tr+Td) |
| Operating Mode | New Mode2, Normally Black, Transmissive |
| Light Source | WLED [8S2P] , W/O Driver |
| Designed For | Mobile Phone |
| Touch Panel | Without |
