| PartNumber | LSC400HM10 |
| Brand | Samsung |
| Size | 40 |
| Application | LCTV |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | CELL |
| Brightness | 0 |
| CR | 4000:1 |
| Colors | 1.07B |
| Backlight | No B/L |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LSC400HM10 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 40 inch |
| Display Mode | PVA, Normally Black, Transmissive |
| Active Area | 885.6×498.15 mm |
| Outline | 899.6×513.95 mm |
| Surface | Antiglare |
| Glass Depth | 0.70+0.70 mm |
| Transmissivity | 5.6% (Typ.)(with Polarizer) |
| Contrast Ratio | 4000:1 (Typ.) |
| Display Colors | 1.07B (8-bit + Dithering), CIE193168% |
| Response Time | 8 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (2 ch, 10-bit), 51 pins |
| Input Voltage | 12.0V (Typ.) |
