| PartNumber | LSM270HP09 |
| Brand | SAMSUNG |
| Size | 27.0 |
| Application | Desktop Monitor Gami |
| Resolution | 1920×1080 |
| Composition | CELL , a-Si TFT-LC |
| Brightness | |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | LVDS |
| Manufacturer | SAMSUNG |
| Screen Size | 27.0 inch |
| Pixel Number | 1920(RGB)×1080 (FHD) 81PPI |
| Active Area(mm) | 597.888 × 336.312 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 0 cd/m² |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Glass Thickness | 0.40+0.40 mm |
| Color Depth | 16.7M 71% NTSC |
| Mass | 650g (Max.) |
| Refresh Rate | 165Hz |
| Signal Type | LVDS (4 ch, 8-bit) , 61 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | LSM270HP09 |
| Screen Type | CELL , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 608.888 × 348.337 × 1.26 (H×V×D) |
| Treatment | Antiglare (Haze 25%) |
| Contrast Ratio | 3000 : 1 (Typ.) (TM) |
| Response | 21 (Typ.)(G to G) ms |
| Work Mode | SPVA, Normally Black, Transmissive |
| Transmissivity | 4.67% (Typ.)(with Polarizer) |
| Used for | Desktop Monitor Gaming |
| Touchscreen | Without |
