| PartNumber | LSM315DP01-M01 |
| Brand | SAMSUNG |
| Size | 32.0 |
| Application | Desktop Monitor Gami |
| Resolution | 2560×1440 |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | eDP |
| Diagonal Size | 32.0 inch |
| Pixel Format | 2560(RGB)×1440 [Quad-HD] 93PPI |
| Active Area | 697.344(H)×392.256(V) mm |
| Bezel Area | - |
| Luminance | 0 cd/m² |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Plate Thickness | 0.40+0.40 mm |
| Support Color | 16.7M 70% NTSC |
| Weight | 900g (Typ.) |
| Frame Rate | 144Hz |
| D-IC Detail | COF Built-in 8 source chips |
| Interface Type | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Model | LSM315DP01-M01 |
| Type | a-Si TFT-LCD , CELL |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 708.944(H)×405.731(V) ×1.11(D) mm |
| Treatment | Antiglare (Haze 25%) |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| Response Time | 22 (Typ.)(G to G) |
| Operating Mode | PVA, Normally Black, Transmissive |
| Transmittance | 3.0% (Typ.)(with Polarizer) |
| Light Source | No B/L |
| Designed For | Desktop Monitor Gaming |
| Touch Panel | Without |
