| PartNumber | LSM315HP01-M02 |
| Brand | SAMSUNG |
| Size | 32.0 |
| Application | Desktop Monitor |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | |
| CR | 3000:1 |
| Colors | - |
| Backlight | No |
| Interface | |
| Diagonal Size | 32.0 inch |
| Pixel Format | 1920(RGB)×1080 [FHD] 69PPI |
| Active Area | 698.4(H)×392.85(V) mm |
| Luminance | 0 cd/m² |
| View Direction | Symmetry |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Support Color | |
| Weight | - |
| Frame Rate | - |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Model | LSM315HP01-M02 |
| Type | a-Si TFT-LCD , CELL |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | - |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| Response Time | 21 (Typ.)(G to G) |
| Operating Mode | PVA, Normally Black, Transmissive |
| Light Source | No B/L |
| Designed For | Desktop Monitor |
| Touch Panel | Without |
