| PartNumber | LT057AC47000 |
| Brand | Toshiba Mobile Display |
| Size | 5.7 |
| Application | Industrial |
| Resolution | 640×480 |
| Composition | LTPS TFT-LCD, LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 262K/16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Model | LT057AC47000 |
| Diagonal Size | 5.7 inch |
| Type | LTPS TFT-LCD, LCM |
| Pixel Format | 640(RGB)×480 [VGA] 141PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 115.2(H)×86.4(V) mm |
| Outline Dim. | - |
| Luminance | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| View Direction | 12 o'clock |
| Response Time | 15/25 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/55/45 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K/16.2M |
| Light Source | WLED , 70K hours |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | - |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
