| PartNumber | LT104V3-100 |
| Brand | Samsung |
| Size | 10.4 |
| Application | NBPC |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | 70 cd/m² (Typ.) |
| CR | 100:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | SAMSUNG |
| Panel Model | LT104V3-100 1 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.4 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 211.2×158.4 mm |
| Outline | 264×180 mm |
| Surface | |
| Contrast Ratio | 100:1 (Min.) |
| Display Colors | 262K (6-bit) |
| Response Time | 20/40 (Typ.)(Tr/Td) |
| Viewing Angle | 48/48/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB, 31 pins |
| Input Voltage | 5.0V (Typ.)(VDD) |
