| PartNumber | LTA320HJ06-W |
| Brand | SAMSUNG |
| Size | 32.0 |
| Application | TV Sets |
| Resolution | 1920×1080 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 5000:1 |
| Colors | 1.07B |
| Backlight | WLED , 35K hours |
| Interface | LVDS |
| Manufacturer | SAMSUNG |
| Screen Size | 32.0 inch |
| Pixel Number | 1920(RGB)×1080 (FHD) 69PPI |
| Active Area(mm) | 698.4 × 392.85 (H×V) |
| Bezel Area(mm) | 705.4 × 400 (H×V) |
| Luminance | 350 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 1.07B 70% NTSC |
| Mass | 5.00/5.5Kgs (Typ./Max.) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (2 ch, 10-bit) , 61 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | LTA320HJ06-W |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 726.2 × 422.9 × 27.9 (H×V×D) |
| Treatment | Antiglare (Haze 2%), Hard coating (2H) |
| Contrast Ratio | 5000 : 1 (Typ.) (TM) |
| Response | 8 (Typ.)(G to G) ms |
| Work Mode | SPVA, Normally Black, Transmissive |
| Used for | TV Sets |
| Touchscreen | Without |
