| PartNumber | LTI750HF01 |
| Brand | Samsung |
| Size | 75 |
| Application | PID |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 2500 cd/m² (Typ.) |
| CR | 5000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTI750HF01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 75 inch |
| Display Mode | SVA, Normally Black, Transmissive |
| Active Area | 1650.24×928.26 mm |
| Outline | 1675.8×953.8×88.8 mm |
| Surface | Glare (Haze 0%) |
| Contrast Ratio | 5000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 6 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 120Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (4 ch, 10-bit), 92 pins |
| Input Voltage | 12.0V (Typ.) |
| LD420WUB-SBA1 | LG Display | 42 | 1920×1080 |
| LD420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| LTI290LN02 | Samsung | 29.0 | 1920×540 |
| LTI320AA02 | Samsung | 31.5 | 1366×768 |
| LTI320AP02 | Samsung | 31.5 | 1366×768 |
| LTI460HA03 | Samsung | 46 | 1920×1080 |
| LTI750HF01 | Samsung | 75 | 1920×1080 |
| P320HVN02.0 | AUO | 31.5 | 1920×1080 |
| P420HVN01.0 | AUO | 42 | 1920×1080 |
| RX366HDL-C07 | ROGIN | 36.6 | 1920×290 |
