| PartNumber | LTL106HL02-001 |
| Brand | Samsung |
| Size | 10.6 |
| Application | PAD |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTL106HL02-001 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.6 inch |
| Display Mode | PLS, Normally Black, Transmissive |
| Active Area | 234.72×132.03 mm |
| Outline | 244.92×145.06×4.56 mm |
| Surface | Glare (Haze 0%), Hard coating (2H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193150% |
| Response Time | 16 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S6PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit), 60 pins |
| Input Voltage | 3.3V (Typ.) |
