| PartNumber | LTM170EU-A01 |
| Brand | Samsung |
| Size | 17.0 |
| Application | DMPC |
| Resolution | 1280(RGB)×1024 , SXGA |
| Composition | LCM |
| Brightness | 270 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 16.2M |
| Backlight | CCFL |
| Interface | Analog |
| Panel Brand | SAMSUNG |
| Panel Model | LTM170EU-A01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 17.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 337.92×270.336 mm |
| Outline | 358.5×296.5×25.4 mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 16.2M (6-bit + FRC), CIE193165% |
| Response Time | 5/20 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 pcsCCFLEmbedded (Inverter) |
| Signal Interface | Analog RGB, 27 pins |
| Input Voltage | 12.0V (Typ.) |
