| PartNumber | LTM190M2-L31(Glare) |
| Brand | Samsung |
| Size | 19.0 |
| Application | DMPC |
| Resolution | 1440(RGB)×900 , WXGA+ |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | SAMSUNG |
| Panel Model | LTM190M2-L31(Glare) |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 19.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 408.24×255.15 mm |
| Outline | 428×278×18.5 mm |
| Surface | Glare (Haze 0%), Hard coating (2H), Reflection 2.0% (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Response Time | 1.3/3.7 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 5.0V (Typ.) |
| AA190EA01 | Mitsubishi | 19.0 | 1280×1024 |
| G190ETN01.2 | AUO | 19.0 | 1280×1024 |
| HSD190MEN3-A00 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN4-A03 | HannStar | 19.0 | 1280×1024 |
| LTM190BT07 | Samsung | 19.0 | 1440×900 |
| LTM190M2-L31 | Samsung | 19.0 | 1440×900 |
| LTM190M2-L31(Glare) | Samsung | 19.0 | 1440×900 |
| M190A1-L07 | Innolux | 19.0 | 1440×900 |
| M190EN04 V5 | AUO | 19.0 | 1280×1024 |
| TMS190WX1-05TB | Tianma | 19.0 | 1440×900 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM170E01-TLA1 | LG Display | 17.0 | 1280×1024 |
| LM190E09-TLD1 | LG Display | 19.0 | 1280×1024 |
| LM200WD3-TLA1 | LG Display | 20.0 | 1600×900 |
| LM270WQ1-SDA2 | LG Display | 27.0 | 2560×1440 |
| LTM150XH-L06 | Samsung | 15.0 | 1024×768 |
| LTM185AT04 | Samsung | 18.5 | 1366×768 |
| LTM230HT09 | Samsung | 23.0 | 1920×1080 |
| M215HGE-P02 | Innolux | 21.5 | 1920×1080 |
| SVA170SX01TB | SVA-NEC | 17.0 | 1280×1024 |
