| PartNumber | LTM230HU01 |
| Brand | Samsung |
| Size | 23.0 |
| Application | DMPC |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | |
| Panel Brand | SAMSUNG |
| Panel Model | LTM230HU01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 23.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 509.76×286.74 mm |
| Surface | |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC) |
| Response Time | |
| Viewing Angle | |
| Lamp Type | 4 pcsCCFLWithout Driver |
