| PartNumber | LTM340YP02 |
| Brand | Samsung |
| Size | 34 |
| Application | DMPC |
| Resolution | 3440(RGB)×1440 |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | SAMSUNG |
| Panel Model | LTM340YP02 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 34 inch |
| Display Mode | PVA, Normally Black, Transmissive |
| Active Area | 799.8×334.8 mm |
| Outline | 811.5×357×18.1 mm |
| Surface | Antiglare (Haze 2.3%), Hard coating (2H) |
| Contrast Ratio | 3000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), sRGB99% |
| Response Time | 14 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 stringsWLEDWithout Driver |
| Signal Interface | eDP (4 Lanes), 50 pins |
| Input Voltage | 12.0V (Typ.) |
| LM170E01-TLA1 | LG Display | 17.0 | 1280×1024 |
| LM170E01-TLB3 | LG Display | 17.0 | 1280×1024 |
| LM215WF3-SDD1 | LG Display | 21.5 | 1920×1080 |
| LM270WQ1-SDBV | LG Display | 27.0 | 2560×1440 |
| LTM150XO-L01 | Samsung | 15.0 | 1024×768 |
| M170EG01 V9 | AUO | 17.0 | 1280×1024 |
| M185B3-LA1 | Innolux | 18.5 | 1366×768 |
| M270DTN01.1 | AUO | 27.0 | 2560×1440 |
| MT170EN01 V.1 | Innolux | 17.0 | 1280×1024 |
| MV238QUM-N20 | BOE | 23.8 | 3840×2160 |
