| PartNumber | LTN173HL01-801 |
| Brand | SAMSUNG |
| Size | 17.3 |
| Application | Laptop |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 700:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 17.3 inch |
| Pixel Format | 1920(RGB)×1080 [FHD] 127PPI |
| Active Area | 381.888(H)×214.812(V) mm |
| Luminance | - |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 262K |
| Form Style | - |
| Frame Rate | 60Hz |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Model | LTN173HL01-801 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | - |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | PLS, Normally Black, Transmissive |
| Light Source | WLED |
| Designed For | Laptop |
| Touch Panel | Without |
