| PartNumber | LTP700WV-F01 |
| Brand | Samsung |
| Size | 7.0 |
| Application | MP4 |
| Resolution | 800×480(RGB) , WVGA |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | SAMSUNG |
| Panel Model | LTP700WV-F01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 7.0 inch |
| Display Mode | TN, Normally White, TMR |
| Active Area | 152.4×91.44 mm |
| Outline | 163.2×104×3.6 mm |
| Surface | |
| Contrast Ratio | 300 : 1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 22.7 (Typ.)(Tr+Td) |
| Viewing Angle | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 8S3PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| Input Voltage | 3.3V (Typ.)(VCC) |
