| PartNumber | M104GNX2 R1 |
| Brand | IVO |
| Size | 10.4 |
| Application | Industrial |
| Resolution | 1024(RGB)×768, XGA, 123PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | - |
| CR | 900:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | IVO |
| Panel Model | M104GNX2 R1 |
| Panel Size | 10.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 211.2(W)×158.4(H) mm |
| Bezel Opening | - |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | - |
| Response Time | 16 (Typ.)(Tr+Td) |
| Display Colors | 262K/16.7M 50% NTSC |
| Lamp Type | WLED |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | - |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
