| PartNumber | M190PW01 V0 |
| Brand | AUO |
| Size | 19.0 |
| Application | DMPC |
| Resolution | 1440(RGB)×900 , WXGA+ |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | M190PW01 V0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 19.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 408.24×255.15 mm |
| Outline | 428×278×19 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Response Time | 3.6/1.4 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 5.0V (Typ.) |
| HSD190MEN4-A03 | HannStar | 19.0 | 1280×1024 |
| LB190E02-SL02 | LG Display | 19.0 | 1280×1024 |
| LTB190E3-L01 | Samsung | 19.0 | 1280×1024 |
| LTM190E4-L03 | Samsung | 19.0 | 1280×1024 |
| M190PP01 V0 | AUO | 19.0 | 1440×900 |
| M190PW01 V0 | AUO | 19.0 | 1440×900 |
| M190PW01 V6 | AUO | 19.0 | 1440×900 |
| M190PW01 V8 | AUO | 19.0 | 1440×900 |
| P190MWW1-404 | IVO | 19.0 | 1440×900 |
| TX48D80VM1CAA | KOE | 19.0 | 1024×768 |
| LTM240CS09 | Samsung | 24.0 | 1920×1200 |
| M150X3-T05 | Innolux | 15.0 | 1024×768 |
| M185BGE-L2U | Innolux | 18.5 | 1366×768 |
| M190CGE-L20 | Innolux | 19.0 | 1440×900 |
| M215HW01 V7 | AUO | 21.5 | 1920×1080 |
| M220Z3-LA3 | Innolux | 22.0 | 1680×1050 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| QD17EL07 Rev.09 | QDI | 17.0 | 1280×1024 |
| TMS150XG1-10TB Rev.E | Tianma | 15.0 | 1024×768 |
