| PartNumber | M200HJJ-L20 Rev.B1 |
| Brand | Innolux |
| Size | 19.5 |
| Application | Desktop Monitor Indu |
| Resolution | 1920×1080 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | 9S4P WLED , 30K hours , No Driver |
| Interface | LVDS |
| Manufacturer | Innolux |
| Screen Size | 19.5 inch |
| Pixel Number | 1920(RGB)×1080 (FHD) 112PPI |
| Active Area(mm) | 434.88 × 238.68 (H×V) |
| Bezel Area(mm) | 438.18 × 241.98 (H×V) |
| Luminance | 250 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 72% NTSC |
| Mass | 1.47±0.08Kgs |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | M200HJJ-L20 Rev.B1 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 459.8 × 263 × 11.82 (H×V×D) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 3000 : 1 (Typ.) (TM) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Work Mode | MVA, Normally Black, Transmissive |
| Used for | Desktop Monitor Industrial |
| Touchscreen | Without |
