| PartNumber | M236HVR01.0 CELL |
| Brand | AUO |
| Size | 23.6 |
| Application | Desktop Monitor Gaming |
| Resolution | 1920(RGB)×1080, FHD, 93PPI |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | 0 cd/m² |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | |
| Panel Brand | AUO |
| Panel Size | 23.6" |
| Display Area | 521.395(W)×293.285(H) mm |
| Outline Size | 532.995(W)×305.185(H) ×1.11(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Glass Depth | 0.40+0.40 mm |
| Display Colors | 16.7M 69% NTSC |
| Frequency | 165Hz |
| Weight | 530g (Typ.) |
| Panel Model | M236HVR01.0 CELL |
| Panel Type | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare (Haze 40%), Hard coating (3H) |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| Display Mode | VA, Normally Black, Transmissive |
| Response Time | 20 (Typ.)(G to G) |
| Transmissivity | 3.22% (Typ.)(with Polarizer) |
| Lamp Type | No B/L |
| Touch Screen | Without |
| HR236WU1-100 | BOE | 23.6 | 1920×1080 |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| M236H3-L05 | Innolux | 23.6 | 1920×1080 |
| M236H3-LA2 | Innolux | 23.6 | 1920×1080 |
| M236HGK-L30 | Innolux | 23.6 | 1920×1080 |
| MV236FHB-N10 | BOE | 23.6 | 1920×1080 |
| P236MWF1 R0 | IVO | 23.6 | 1920×1080 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P02 | Innolux | 23.6 | 1366×768 |
