| PartNumber | M238DAN01.1Q0 |
| Brand | AUO |
| Size | 23.8 |
| Application | Desktop Monitor |
| Resolution | 2560(RGB)×1440, Quad-HD, 123PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 20S4P |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | M238DAN01.1Q0 |
| Panel Size | 23.8" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 526.85(W)×296.35(H) mm |
| Bezel Opening | - |
| Outline Size | 534.74(W)×313.26(H) ×12.3(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 14 (Typ.)(G to G) |
| Display Colors | 16.7M 100% sRGB |
| Lamp Type | 20S4P WLED , 30K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 2.20Kgs (Typ.) |
| Signal Interface | LVDS (4 ch, 8-bit) , 92 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
