| PartNumber | M270DTN01.00E |
| Brand | AUO |
| Size | 27.0 |
| Application | Desktop Monitor Gaming |
| Resolution | 2560(RGB)×1440, Quad-HD, 108PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 18S4P |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | M270DTN01.00E |
| Panel Size | 27.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 596.736(W)×335.664(H) mm |
| Bezel Opening | 601.6(W)×340.15(H) mm |
| Outline Size | 613.6(W)×356.85(H) ×10.9(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | - |
| Response Time | 3.5/1.5 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | 18S4P WLED , 30K hours , Without Driver |
| Frequency | 165Hz |
| Touch Screen | Without |
| Panel Weight | 2.20/2.31Kgs (Typ./Max.) |
| Signal Interface | LVDS (8 ch, 8-bit) , 130 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
