| PartNumber | M280HKJ-L30 |
| Brand | Innolux |
| Size | 28.0 |
| Application | DMPC |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | CHIMEI INNOLUX |
| Panel Model | M280HKJ-L30 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 28.0 inch |
| Display Mode | MVA, Normally Black, Transmissive |
| Active Area | 620.928×341.28 mm |
| Outline | 649.3×369.6×15.3 mm |
| Surface | Antiglare (Haze 3.4%), Hard coating (3H) |
| Contrast Ratio | 3000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 6.5 (Typ.)(G to G) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 stringsWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 12.0V (Typ.) |
