| PartNumber | M320QAN01.2 |
| Brand | AUO |
| Size | 32.0 |
| Application | Desktop Monitor |
| Resolution | 3840×2160 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 1.07B |
| Backlight | 4 strings × 2CN KSF LED , No Driver |
| Interface | eDP |
| Manufacturer | AUO |
| Screen Size | 32.0 inch |
| Pixel Number | 3840(RGB)×2160 (UHD) 137PPI |
| Active Area(mm) | 708.48 × 398.52 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 300 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 1.07B 100% Adobe RGB |
| Mass | 3.90Kgs (Typ.) |
| Refresh Rate | 60Hz |
| Signal Type | eDP (8 Lanes) , HBR1 (2.7G/lane) , 41 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | M320QAN01.2 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 721.88 × 417.93 × 17.37 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Response | 12 (Typ.)(G to G) ms |
| Work Mode | AHVA, Normally Black, Transmissive |
| Used for | Desktop Monitor |
| Touchscreen | Without |
