| PartNumber | MCG156FDLAAQNN-AN20 |
| Brand | Kyocera |
| Size | 15.6 |
| Application | Industrial |
| Resolution | 1920(RGB)×1080, FHD, 141PPI |
| Composition | LTPS TFT-LCD , LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.2M |
| Backlight | WLED |
| Interface | |
| Panel Brand | Kyocera |
| Panel Size | 15.6" |
| Display Area | 344.16(W)×193.59(H) mm |
| Outline Size | 363.8(W)×215.9(H) ×9.8(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.2M 73% NTSC |
| Frequency | 60Hz |
| Weight | 1.05/1.09Kgs (Typ./Max.) |
| Panel Model | MCG156FDLAAQNN-AN20 |
| Panel Type | LTPS TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 347.06(W)×196.49(H) mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | AWV, Normally Black, Transmissive |
| Response Time | 13/12 (Typ.)(Tr/Td) |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Touch Screen | Without |
