| PartNumber | MLAF061WE51 X |
| Brand | Mantix |
| Size | 6.1 |
| Application | Mobile Phone |
| Resolution | 720(RGB)×1560, 282PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | |
| Panel Brand | Mantix |
| Panel Model | MLAF061WE51 X |
| Panel Size | 6.1" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 64.8(W)×140.4(H) mm |
| Bezel Opening | - |
| Outline Size | 66.6(W)×145.3(H) ×0.3(D) mm |
| Surface | Without Polarizer |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | FFS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Glass Depth | 0.15+0.15 mm |
| Transmissivity | 3.9% (Typ.)(with Polarizer) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | No B/L |
| Frequency | - |
| Touch Screen | In-Cell Touch |
| Driver IC | COGSuggest ICNL9911, FT8006P, ILI9881H, ICNL9911S, NT36525B, HX83102-D |
| Panel Weight | - |
| Input Voltage | 1.8/5.5/-5.5V (Typ.)(IOICC/VSP/VSN) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
