| PartNumber | MND307DA1-8 |
| Brand | CSOT |
| Size | 13.3 |
| Application | Laptop |
| Resolution | 2560(RGB)×1600, WQXGA, 227PPI |
| Composition | LTPS TFT-LCD , LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | CSOT |
| Panel Size | 13.3" |
| Display Area | 286.08(W)×178.8(H) mm |
| Outline Size | 291.08(W)×195.3(H) ×2.4(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 99% sRGB |
| Frequency | 60Hz |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (4 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | MND307DA1-8 |
| Panel Type | LTPS TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Display Mode | FFS, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) |
| Lamp Type | WLED , 15K hours , With LED Driver |
| Touch Screen | Without |
