| PartNumber | MNE001EA1-1 |
| Brand | CSOT |
| Size | 14.0 |
| Application | Laptop |
| Resolution | 3840(RGB)×2160, UHD, 315PPI |
| Composition | LTPS TFT-LCD , LCM |
| Brightness | - |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | CSOT |
| Panel Size | 14.0" |
| Display Area | 309.31(W)×173.99(H) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M |
| Frequency | 60Hz |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP Connector |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | MNE001EA1-1 |
| Panel Type | LTPS TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Display Mode | FFS, Normally Black, Transmissive |
| Response Time | - |
| Lamp Type | WLED |
| Touch Screen | - |
