MT190AW02 V.W

MT190AW02 V.W
MT190AW02 V.W
MT190AW02 V.W
MT190AW02 V.W thumb MT190AW02 V.W thumb MT190AW02 V.W thumb
Brand
Innolux
Size
19.0
Application
DMPC
Resolution
1440×900
Composition
LCM
Brightness
250
CR
1000:1
Colors
16.7M
Backlight
WLED
Interface
LVDS
In Stock
225
Specifications
PartNumber MT190AW02 V.W
BrandInnolux
Size19.0
ApplicationDMPC
Resolution1440(RGB)×900 , WXGA+
CompositionLCM
Brightness250 cd/m² (Typ.)
CR1000:1
Colors16.7M
BacklightWLED
InterfaceLVDS
Panel BrandINNOLUX
Panel ModelMT190AW02 V.W
Panel Type a-Si TFT-LCD , LCM
Panel Size19.0 inch
Display ModeTN, Normally White, Transmissive
Active Area408.24×255.15 mm
Outline428×278 mm
SurfaceAntiglare (Haze 25%), Hard coating (3H)
Contrast Ratio1000:1 (Typ.)
Display Colors16.7M (6-bit + Hi-FRC), CIE193168%
Response Time1.5/3.5 (Typ.)(Tr/Td)
Viewing Angle85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
Frequency60Hz
Lamp Type5 stringsWLEDWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Voltage5.0V (Typ.)
Family Model
HSD190MEN4-A03 HannStar 19.0 1280×1024
MT190AW01 V.5 Innolux 19.0 1440×900
MT190AW01 V.7 Innolux 19.0 1440×900
MT190AW01 V.C Innolux 19.0 1440×900
MT190AW02 V.0 Innolux 19.0 1440×900
MT190AW02 V.4 Innolux 19.0 1440×900
MT190AW02 V.A Innolux 19.0 1440×900
MT190AW02 V.V Innolux 19.0 1440×900
MT190AW02 V.W Innolux 19.0 1440×900
MT190AW02 V.Y Innolux 19.0 1440×900
