| PartNumber | MT5461D01-1 |
| Brand | CSOT |
| Size | 55 |
| Application | LCTV |
| Resolution | 3840(RGB)×2160 , UHD |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 4000:1 |
| Colors | 1.07B |
| Backlight | WLED |
| Interface | V-by-One |
| Panel Brand | CSOT |
| Panel Model | MT5461D01-1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 55 inch |
| Display Mode | HVA, Normally Black, Transmissive |
| Active Area | 1209.6×680.4 mm |
| Outline | 1225.8×696.6×33.8 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 4000:1 (Typ.) |
| Display Colors | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Response Time | 6.5 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 120Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | V-by-One 8 lane, 51 pins |
| Input Voltage | 12.0V (Typ.) |
