| PartNumber | MV185WHB-N20 |
| Brand | BOE |
| Size | 18.5 |
| Application | Desktop Monitor |
| Resolution | 1366×768 |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | LVDS |
| Model | MV185WHB-N20 |
| Diagonal Size | 18.5 inch |
| Type | a-Si TFT-LCD, CELL |
| Pixel Format | 1366(RGB)×768 [WXGA] 84PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 409.8(H)×230.4(V) mm |
| Outline Dim. | 422.2(H)×244.1(V) ×1.32(D) mm |
| Bezel Area | - |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 14 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | HADS, Normally Black, Transmissive |
| Plate Thickness | 0.50+0.50 mm |
| Transmittance | 6.0% (Typ.)(with Polarizer) |
| Support Color | 16.7M 72% NTSC |
| Light Source | No B/L |
| Weight | 327g (Typ.) |
| Designed For | Desktop Monitor |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| D-IC Detail | COF Built-in 2 source chips |
| Interface Type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| G185HAN01.0 | AUO | 18.5 | 1920×1080 |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| M185B1-L02 | Innolux | 18.5 | 1366×768 |
| M185XW01 VF | AUO | 18.5 | 1366×768 |
| MT185GW01 V.4 | Innolux | 18.5 | 1366×768 |
