| PartNumber | N116BCA-EB1 |
| Brand | Innolux |
| Size | 11.6 |
| Application | Laptop |
| Resolution | 1366(RGB)×768, WXGA, 135PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 220 cd/m² (Typ.) |
| CR | - |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Panel Brand | Innolux |
| Panel Size | 11.6" |
| Display Area | 256.125(W)×144(H) mm |
| Viewing Angle | - |
| Best View on | Symmetry |
| Display Colors | 262K 45% NTSC |
| Frequency | 60Hz |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Panel Model | N116BCA-EB1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Contrast Ratio | - |
| Display Mode | AAS, Normally Black, Transmissive |
| Response Time | - |
| Lamp Type | WLED |
| Touch Screen | Without |
