N133HCR-GA1


Brand
Innolux
Size
13.3
Application
Laptop
Resolution
1920×1080
Composition
LCM ,   a-Si TFT-LCD
Brightness
CR
1000:1
Colors
16.7M
Backlight
WLED
Interface
In Stock
14361
Specifications
PartNumber N133HCR-GA1
BrandInnolux
Size13.3
ApplicationLaptop
Resolution1920×1080
CompositionLCM ,   a-Si TFT-LCD
Brightness
CR1000:1
Colors16.7M
BacklightWLED , 15K hours , With LED Driver
Interface
ManufacturerInnolux
Screen Size13.3 inch
Pixel Number1920(RGB)×1080   (FHD)  166PPI
Active Area(mm)293.76 × 165.24 (H×V)
Bezel Area(mm)-
Luminance400 (Typ.)(cd/m²)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Good View atSymmetry
Color Depth16.7M   100% sRGB
Outline ShapeSlim (PCBA Flat, T≤3.2mm)
Refresh Rate60Hz
Model NameN133HCR-GA1 (CMN13A2)
Screen TypeLCM ,   a-Si TFT-LCD
ArrangementRGB Vertical Stripe
Outline(mm)300.26 × 188.25 × 3 (H×V×D)
TreatmentAntiglare, Hard coating (3H)
Contrast Ratio1000 : 1 (Typ.) (TM)
Work ModeAAS, Normally Black, Transmissive
Response14/11 (Typ.)(Tr/Td) ms
Used forLaptop
TouchscreenWithout
