| PartNumber | N154C6-L04 |
| Brand | Innolux |
| Size | 15.4 |
| Application | NBPC |
| Resolution | 1440(RGB)×900 , WXGA+ |
| Composition | LCM |
| Brightness | 330 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | CMO |
| Panel Model | N154C6-L04 8 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 15.4 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 331.344×207.09 mm |
| Outline | 342.85×229.89×4.03 mm |
| Shape Style | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| Surface | Glare (Haze 0%), Hard coating (3H) |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 3/7 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/70/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 10S6PWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
| CLAA154WA01 | CPT | 15.4 | 1280×800 |
| CLAA154WA05A | CPT | 15.4 | 1280×800 |
| LP154W01-TLAA | LG Display | 15.4 | 1280×800 |
| LP154WE2-TLA3 | LG Display | 15.4 | 1680×1050 |
| LP154WP4-TLA1 | LG Display | 15.4 | 1440×900 |
| LTN154AT09-201 | Samsung | 15.4 | 1280×800 |
| LTN154CT03-D01 | Samsung | 15.4 | 1920×1200 |
| N154C1-L01 | Innolux | 15.4 | 1440×900 |
| N154C3-L02 | Innolux | 15.4 | 1440×900 |
| N154C6-L04 | Innolux | 15.4 | 1440×900 |
| B141PW04 V0 HW1A | AUO | 14.1 | 1440×900 |
| B154PW02 V3 | AUO | 15.4 | 1440×900 |
| LP125WF2-SPB3 | LG Display | 12.5 | 1920×1080 |
| LP140WF1-SPU1 | LG Display | 14.0 | 1920×1080 |
| LP154W01-TLA2 | LG Display | 15.4 | 1280×800 |
| LTD121EX1R | TOSHIBA | 12.1 | 1280×768 |
| LTN140AT08-S03 | Samsung | 14.0 | 1366×768 |
| LTN156AT36-D01 | Samsung | 15.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| N156B6-L01 | Innolux | 15.6 | 1366×768 |
