| PartNumber | NE133FHM-N57 |
| Brand | BOE |
| Size | 13.3 |
| Application | Laptop |
| Resolution | 1920(RGB)×1080, FHD, 166PPI |
| Composition | Oxide TFT-LCD , LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 10S6P |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Size | 13.3" |
| Display Area | 293.76(W)×165.24(H) mm |
| Outline Size | 298.76(W)×181.33(H) ×2.44(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 100% DCI-P3 |
| Frequency | 60Hz |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 70 °C |
| Panel Model | NE133FHM-N57 (BOE087A) |
| Panel Type | Oxide TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | FFS, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td); 25 (Typ.)(G to G) |
| Lamp Type | 10S6P QLED , 15K hours , Without Driver |
| Touch Screen | Without |
