| PartNumber | NE135FBM-N41 |
| Brand | BOE |
| Size | 13.5 |
| Application | Laptop |
| Resolution | 2256(RGB)×1504, 201PPI |
| Composition | Oxide TFT-LCD, LCM |
| Brightness | 415 cd/m² (Typ.) |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | 9S6P |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Model | NE135FBM-N41 (BOE08BC BOE095F) |
| Panel Size | 13.5" |
| Panel Type | Oxide TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 284.933(W)×189.955(H) mm |
| Bezel Opening | - |
| Outline Size | 289.993(W)×212.28(H) ×2.1(D) mm |
| Surface | Hard coating (2H) |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | FFS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 100% sRGB |
| Lamp Type | 9S6P WLED , 15K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
