| PartNumber | NE156QUM-N64 |
| Brand | BOE |
| Size | 15.6 |
| Application | Laptop |
| Resolution | 3840(RGB)×2160, UHD, 283PPI |
| Composition | Oxide TFT-LCD , LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 10S6P |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Size | 15.6" |
| Display Area | 344.218(W)×193.622(H) mm |
| Outline Size | 350.52(W)×205.92(H) ×4.6(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 72% NTSC |
| Frequency | 60Hz |
| Shape Style | Slim (PCBA Bent, T≤3.0mm) |
| Signal Interface | eDP (4 Lanes) , eDP1.4a , HBR2 (5.4G/lane) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | NE156QUM-N64 (BOE07D9) |
| Panel Type | Oxide TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | ADS, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) |
| Lamp Type | 10S6P WLED , 15K hours , With LED Driver |
| Touch Screen | Without |
