| PartNumber | NL12880BC20-25F |
| Brand | NLT |
| Size | 12.1 |
| Application | Industrial Outdoor H |
| Resolution | 1280×800 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 262K/16.7M |
| Backlight | 3 strings WLED , 60K hours , No Driver |
| Interface | LVDS |
| Manufacturer | NLT |
| Model Name | NL12880BC20-25F |
| Screen Size | 12.1 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×800 (WXGA) 124PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 261.12 × 163.2 (H×V) |
| Outline(mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| Bezel Area(mm) | 266.1 × 168.2 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 1600 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 15 (Typ.)(Tr+Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K/16.7M 50% NTSC |
| Mass | 470g (Typ.) |
| Used for | Industrial Outdoor High Brightness |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
