| PartNumber | NL160120AC27-37 |
| Brand | NLT |
| Size | 21.3 |
| Application | MD |
| Resolution | 1600(RGB)×1200 , UXGA |
| Composition | LCM |
| Brightness | 900 cd/m² (Typ.) |
| CR | 1400:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | NLT |
| Panel Model | NL160120AC27-37 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 21.3 inch |
| Display Mode | SFT, Normally Black, Transmissive |
| Active Area | 432×324 mm |
| Outline | 457×350×22 mm |
| Surface | Antiglare, Hard coating (2H) |
| Contrast Ratio | 1400:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 20/20 (Typ.)(Tr/Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 12.0V (Typ.) |
