| PartNumber | NL256204AM15-02A |
| Brand | NLT |
| Size | 20.1 |
| Application | DMPC |
| Resolution | 2560(LCR)×2048 , QSXGA |
| Composition | LCM |
| Brightness | 850 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | Grayscale |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | NEC |
| Panel Model | NL256204AM15-02A |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 20.1 inch |
| Display Mode | SA-SFT, Normally Black, Transmissive |
| Active Area | 399.36×319.49 mm |
| Outline | 423.4×343.5×45.5 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | Grayscale (8-bit) |
| Response Time | 15/15 (Typ.)(Tr/Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 12 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (4 ch, 8-bit) |
| Input Voltage | 12.0V (Typ.) |
| RoHS: |
