| PartNumber | NL3224AC35-09 |
| Brand | NEC |
| Size | 5.5 |
| Application | Industrial |
| Resolution | 320(RGB)×240, QVGA, 72PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | - |
| CR | 400:1 |
| Colors | 262K |
| Backlight | - |
| Interface | |
| Panel Brand | NEC |
| Panel Size | 5.5" |
| Display Area | 111.36(W)×83.52(H) mm |
| Viewing Angle | - |
| Best View on | - |
| Display Colors | 262K |
| Frequency | 60Hz |
| Weight | - |
| Panel Model | NL3224AC35-09 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 5/25 (Typ.)(Tr/Td) |
| Lamp Type | |
| Touch Screen | Without |
