| PartNumber | NT116WHM-A20 |
| Brand | BOE |
| Size | 11.6 |
| Application | Laptop |
| Resolution | 1366(RGB)×768, WXGA, 135PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | 8S4P |
| Interface | |
| Panel Brand | BOE |
| Panel Size | 11.6" |
| Display Area | 256.125(W)×144(H) mm |
| Outline Size | 278(W)×171.55(H) ×4.9(D) mm |
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥10) |
| Best View on | 6 o'clock |
| Display Colors | 262K 48% NTSC |
| Frequency | 60Hz |
| Shape Style | Flat (PCBA Flat, T3.4~4.0mm) |
| Panel Model | NT116WHM-A20 (BOE063F) |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Hard coating (7H) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 12 (Typ.)(Tr+Td) |
| Lamp Type | 8S4P WLED , 15K hours , With LED Driver |
| Touch Screen | PCAP, Optical Bonding |
