| PartNumber | NT133WHM-N23 |
| Brand | BOE |
| Size | 13.3 |
| Application | Laptop |
| Resolution | 1366(RGB)×768, WXGA, 118PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 220 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | 9S4P |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Size | 13.3" |
| Display Area | 293.42(W)×164.97(H) mm |
| Outline Size | 306.3(W)×188.75(H) ×3.6(D) mm |
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥10) |
| Best View on | 6 o'clock |
| Display Colors | 262K 48% NTSC |
| Frequency | 60Hz |
| Shape Style | Flat (PCBA Flat, T3.4~4.0mm) |
| Signal Interface | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| Panel Model | NT133WHM-N23 (BOE06D8) |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 12 (Typ.)(Tr+Td) |
| Lamp Type | 9S4P WLED , 15K hours , With LED Driver |
| Touch Screen | Without |
| B133XW07 V2 | AUO | 13.3 | 1366×768 |
| LP133WH2-TLA3 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL2 | LG Display | 13.3 | 1366×768 |
| LP133WP1-TJA7 | LG Display | 13.3 | 1440×900 |
| LTN133AT05-S02 | Samsung | 13.3 | 1280×800 |
| M133NWF2 R0 | IVO | 13.3 | 1920×1080 |
| M133NWN1 R1 | IVO | 13.3 | 1366×768 |
| N133B6-L02 | Innolux | 13.3 | 1366×768 |
| N133BGE-LB1 | Innolux | 13.3 | 1366×768 |
| TM133XG-02L07A | SANYO | 13.3 | 1024×768 |
