| PartNumber | NT156WHM-N42 |
| Brand | BOE |
| Size | 15.6 |
| Application | NBPC |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | 220 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Model | NT156WHM-N42 8 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 15.6 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 344.232×193.536 mm |
| Outline | 359.5×223.8×3.2 mm |
| Shape Style | Slim (PCBA Flat, Depth ≤3.2mm) |
| Surface | Antiglare |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193145% |
| Response Time | 12 (Typ.)(Tr+Td) |
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 9S4PWLEDEmbedded (LED Driver) |
| Signal Interface | eDP (1 Lane), 30 pins |
| Input Voltage | 3.3V (Typ.) |
| G156BGE-L01 | Innolux | 15.6 | 1366×768 |
| LP156WH4-TLN2 | LG Display | 15.6 | 1366×768 |
| LTN156AT05-J08 | Samsung | 15.6 | 1366×768 |
| LTN156AT30-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT32-L01 | Samsung | 15.6 | 1366×768 |
| NT156WHM-N10 | BOE | 15.6 | 1366×768 |
| NT156WHM-N12 | BOE | 15.6 | 1366×768 |
| NT156WHM-N33 | BOE | 15.6 | 1366×768 |
| NT156WHM-N42 | BOE | 15.6 | 1366×768 |
| NT156WHM-N50 | BOE | 15.6 | 1366×768 |
| B133XW01 V2 | AUO | 13.3 | 1366×768 |
| B140XTN02.4 | AUO | 14.0 | 1366×768 |
| B141EW05 V5 | AUO | 14.1 | 1280×800 |
| B141XG03 V2 | AUO | 14.1 | 1024×768 |
| B150XG02 V4 | AUO | 15.0 | 1024×768 |
| B156XW03 V1 | AUO | 15.6 | 1366×768 |
| CLAA154WB04N | CPT | 15.4 | 1280×800 |
| LTM10C348P | TOSHIBA | 10.4 | 800×600 |
| LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
| LTN156AT32-L01 | Samsung | 15.6 | 1366×768 |
