| PartNumber | NV133FHM-N4T |
| Brand | BOE |
| Size | 13.3 |
| Application | Laptop |
| Resolution | 1920×1080 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 262K |
| Backlight | 8S4P WLED , 15K hours , With LED Driver |
| Interface | eDP |
| Manufacturer | BOE |
| Screen Size | 13.3 inch |
| Pixel Number | 1920(RGB)×1080 (FHD) 166PPI |
| Active Area(mm) | 293.76 × 165.24 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 250 cd/m² (Typ.) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 262K 45% NTSC |
| Outline Shape | Slim (PCBA Bent, T≤3.0mm) |
| Refresh Rate | 60Hz |
| Signal Type | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | NV133FHM-N4T (BOE08A5) |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 300.26 × 174.47 × 5 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Response | 30 (Typ.)(Tr+Td) ms |
| Work Mode | ADS, Normally Black, Transmissive |
| Used for | Laptop |
| Touchscreen | Without |
| B133EW03 V1 | AUO | 13.3 | 1280×800 |
| LP133WP1-TJA7 | LG Display | 13.3 | 1440×900 |
| LP133WQ1-SJA1 | LG Display | 13.3 | 2560×1600 |
| LP133WX1-TLC1 | LG Display | 13.3 | 1280×800 |
| LTN133AT01-003 | Samsung | 13.3 | 1280×800 |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT23-B01 | Samsung | 13.3 | 1366×768 |
| N133HSE-EA3 | Innolux | 13.3 | 1920×1080 |
| NV133FHM-N43 | BOE | 13.3 | 1920×1080 |
| NV133FHM-N52 | BOE | 13.3 | 1920×1080 |
