| PartNumber | NV140DRM-N61 |
| Brand | BOE |
| Size | 14.0 |
| Application | Laptop |
| Resolution | 2240(RGB)×1400, 188PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | 10S5P |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Size | 14.0" |
| Display Area | 301.526(W)×188.454(H) mm |
| Outline Size | 306.55(W)×204.47(H) ×2.8(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 100% sRGB |
| Frequency | 60Hz |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (4 Lanes) , eDP1.4 , RBR (1.62G/lane) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | NV140DRM-N61 (BOE0931) |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Display Mode | ADS, Normally Black, Transmissive |
| Response Time | 20 (Typ.)(Tr+Td) |
| Lamp Type | 10S5P WLED , 15K hours , With LED Driver |
| Touch Screen | Without |
