| PartNumber | NV140QUM-N51 |
| Brand | BOE |
| Size | 14.0 |
| Application | Laptop |
| Resolution | 3840(RGB)×2160, UHD, 315PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | 10S6P |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Model | NV140QUM-N51 (BOE06DE) |
| Panel Size | 14.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 309.31(W)×173.99(H) mm |
| Bezel Opening | - |
| Outline Size | 315.01(W)×194.66(H) ×2.4(D) mm |
| Surface | - |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 35 (Max.)(Tr+Td) |
| Display Colors | 16.7M 100% sRGB |
| Lamp Type | 10S6P WLED , 15K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (4 Lanes) , HBR2 (5.4G/lane) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -20 ~ 65 °C |
