NVK16BSC001G-C-0000

NVK16BSC001G-C-0000
NVK16BSC001G-C-0000
NVK16BSC001G-C-0000
NVK16BSC001G-C-0000 thumb NVK16BSC001G-C-0000 thumb NVK16BSC001G-C-0000 thumb
Brand
Neoview Kolon
Size
1.7
Application
SB
Resolution
80×168
Composition
OLED
Brightness
250
CR
Colors
262K
Backlight
self
Interface
CPU
In Stock
19654
Specifications
PartNumber NVK16BSC001G-C-0000
BrandNeoview Kolon
Size1.7
ApplicationSB
Resolution80(RGB)×168
CompositionOLED
Brightness250 cd/m² (Typ.)
CR
Colors262K
Backlightself
InterfaceCPU
Panel BrandNeoview Kolon
Panel ModelNVK16BSC001G-C-0000
Panel Type PM-OLED , OLED
Panel Size1.7 inch
Active Area18.446×38.782 mm
Outline26×50 mm
Surface
Contrast Ratio
Display Colors262K (6-bit)
Viewing Angle
Driver ICBuilt-in SSD1352
Signal Interface8-bit 8080 parallel
Input Voltage2.8/1.8/16V (Typ.)(VCI/VCCIO/VCC)
