| PartNumber | P0650VGF1MA10 |
| Brand | TIANMA |
| Size | 6.5 |
| Application | Industrial Outdoor High Brightness Automotive Display |
| Resolution | 640(RGB)×480, VGA, 122PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 800 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | 262K/16.7M |
| Backlight | 6S2P |
| Interface | LVDS |
| Panel Brand | TIANMA |
| Panel Model | P0650VGF1MA10 |
| Panel Size | 6.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 132.48(W)×99.36(H) mm |
| Bezel Opening | 135.48(W)×102.36(H) mm |
| Outline Size | 153(W)×118(H) ×11.2(D) mm |
| Surface | Antiglare |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | SFT, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 262K/16.7M 70% NTSC |
| Lamp Type | 6S2P WLED , 70K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | TBD |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| DJ065NA-01C | Innolux | 6.5 | |
| L5F30818P03 | SONY | 6.5 | 800×480 |
| L5F30947T00 | Epson | 6.5 | 800×480 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LB065WQ3-TD02 | LG Display | 6.5 | 400×240 |
| LQ065T9DZ03 | SHARP | 6.5 | 400×240 |
| LQ065Y5DG01 | SHARP | 6.5 | 800×480 |
| LQ065Y5DG03 | SHARP | 6.5 | 800×480 |
| LQ065Y5DZ01 | SHARP | 6.5 | 800×480 |
| LTA065B0F0F | TOSHIBA | 6.5 | 800×480 |
